6MP USB 3.0 Microscope Camera
6MP USB 3.0 Microscope Camera
Couldn't load pickup availability
The 6MP is a 6MP colour camera suited to bright-field microscopic imaging. With real-time image stitching, depth-of-field fusion and a high-speed USB 3.0 interface, it helps you work efficiently without paying for capability you don't need. It's a strong choice for anyone looking for an economical, dependable camera.
- Live image stitching. Builds a large mosaic image in seconds as you move the stage, quickly and smoothly.
- Live EDF (depth-of-field fusion). As you turn the focus ring across different focal points, the camera generates a clear, large depth-of-field image, quickly and accurately.
- 6MP resolution. A resolution widely used across microscopy applications, suited to both biological and industrial imaging.
Specifications
| Sensor | Sony IMX178, CMOS, colour |
| Sensor size | 1/1.8" |
| Resolution | 6MP (3072 × 2048) |
| Pixel size | 2.4 × 2.4 μm |
| Shutter mode | Rolling |
| Frame rate | 41fps @ 3072 × 2048; 41fps @ 1536 × 1024 (2×2 bin) |
| Exposure time | 0.13ms – 15s |
| Exposure control | Auto / manual |
| White balance | Auto |
| Colour temperature range | 2000 – 15000K |
| Colour processing | 12-bit ISP |
| File formats | JPG, PNG, TIFF |
| Interface | USB 3.0 |
| Mount | Standard C-mount |
| Software | Mosaic V3.0 |
| Operating system | Windows 7/8/10 (64-bit) |
| System requirements | Intel Core i5 (quad-core) or better, 8GB RAM or more |
| Multi-camera | Up to 4 cameras via SDK |
| Dimensions | 68 × 68 × 46mm |
| Weight | 330g |
| Warranty | 1 year hardware, 3 month software support |
FAQ
Do I need a computer to use this camera?
Yes. It connects by USB 3.0 to a Windows PC running Mosaic V3.0.
Which C-mount adapter do I need?
The camera requires a standard C-mount adaptor. Adaptor choice depends on your microscope, so ensure you select the correct adaptor when purchasing.
Is it suitable for fluorescence imaging?
It handles fluorescence work at exposures up to 15 seconds, and Mosaic V3.0 includes fluorescence image synthesis and editing. As a rolling shutter camera, it suits static samples best.
Which file formats and operating systems are supported?
JPG, PNG and TIFF, on Windows 7/8/10 (64-bit).
Can I get a formal quote?
Yes. Contact us with your institution details and we'll provide one.
